Versatile Solar Energy System Ground Mounting Structures for Various Applications

Galvanized Steel Ground Mounting Structure

The Huitai C-channel steel solar ground mounting system is a customizable fixed-tilt racking structure for commercial, industrial and open-field photovoltaic projects. C-shaped steel posts, beams and braces create the main supporting structure, while guide rails, clamps, fasteners and foundation components complete the array. Hot-dip galvanized and zinc-aluminum-magnesium coating options are available according to the specified project environment.

For an overview of other materials and structural configurations, visit our PV ground mounting system range.

Why Use a C-Channel Steel Ground Mount?

A C-channel steel PV mounting structure provides several practical advantages for project procurement and installation:

• ♦   Steel channels can be configured into posts, inclined beams and bracing according to the array layout.

• ♦   Bolted mechanical connections simplify component replacement and on-site assembly.

• ♦   Row quantity and support spacing can be adapted to module dimensions and project loads.

• ♦   Hot-dip galvanized or Zn-Al-Mg coated surfaces provide options for long-term outdoor exposure.

• ♦   Ground screw and concrete-embedded foundation arrangements are available for different site conditions.

Components and Supply Scope

A project-specific C-channel steel solar ground mounting system may include:

• ♦   C-shaped steel posts, beams and inclined supports

• ♦   Guide rails or purlins

• ♦   Solar panel end and middle clamps

• ♦   Pressure plates and connection brackets

• ♦   Nuts, bolts, washers and gaskets

• ♦   Steel ground screws or concrete foundation connections

• ♦   Project-specific packing list and bill of materials

The final component dimensions and quantities are confirmed after the module layout and foundation arrangement have been reviewed. Huitai’s technical support team can provide installation documentation and remote assistance for project managers, installers and distributors.

Why Choose Huitai

Huitai manufactures solar mounting systems, steel channels, rails, clamps, fasteners and other related components.

Customization is available for structural dimensions, material selection, surface treatment, module layout, packing and project documentation. Production-stage inspections help verify component dimensions, coating condition, fastener matching and packing-list completeness.

Contact Huitai with your module datasheet, layout and site requirements to discuss a custom C-channel steel solar ground mounting system.
