Aluminum Tile Roof Solar Mounting System
A lightweight modular AL6005-T5 Aluminum Tile Roof Solar mounting system for residential and commercial tile roof PV projects. AL6005-T5 aluminum rails and clamps reduce rooftop handling weight, while standardized connections simplify installation and project-kit preparation.
Best suited for: residential installers, commercial rooftop EPCs, distributors and buyers prioritizing low system weight, modular components and faster installation.
10-Year Warranty Solar Panel Mounting System
25-Year Service Life PV Mounting Brackets
216km/h Wind Load Solar Panel Roof Mounting Brackets
Certificate: CE,ISO9001,SGS
Share
Production Description
Lightweight AL6005-T5 solar racking with SUS304 roof hooks for residential and commercial tile roof PV projects.
The Huitai aluminum tile roof solar mounting system provides a complete racking solution for installing framed PV modules on pitched tile roofs. The system combines anodized AL6005-T5 aluminum rails with corrosion-resistant SUS304 roof hooks and fasteners, providing a lightweight yet structurally stable mounting solution.
Designed for Spanish, Roman, hollow, flat, standard and double-slot roof tiles, this aluminum solar mounting system for tile roofs can be configured according to the tile profile, roof structure, module dimensions and local wind and snow conditions.
| China | Solar Tile Roof Mounting System | Certification | ISO, CB, CE | |
| Application | Home, Industrial, Commercial | Specification | Normal, Customized | |
| Material | Stainless Steel 304&Aluminum 6005-T5 | Surface Treatment | Anodizing 13 Um/Sand Blasting | |
| Installation Angle | 90° or 180° | Max Wind Speed | up To130mph(60m/S) | |
| Design Snow Load | up to 30PSF(1.4kN/M2) | Design Standard | JIS C 8955:2011,GB50009-2012,1bc 2009.Cbc2010 | |
| Panel Direction | Vertical or Landscape | Packing | Cardboard Box, Custom Pallet or Custom Wooden Box | |
| Transport Package | Customized | Trademark | HUITAI |
Different tile profiles require different roof hook shapes and adjustment ranges. This system can be configured for:
For non-standard tiles, buyers can provide tile drawings, dimensions or site photographs. The roof hook position, height and clearance can then be adjusted to reduce contact between the hook and the tile.
A project-specific tile roof solar mounting kit can include:
| Component | Function |
|---|---|
| Tile roof hooks | Connect the mounting structure to roof rafters or supporting members |
| Aluminum mounting rails | Support and align the PV modules |
| Rail connectors | Join rail sections for longer module rows |
| Mid clamps | Secure adjacent PV modules |
| End clamps | Secure modules at the outer edges of each row |
| SUS304 fasteners | Connect hooks, rails, clamps and other components |
| Grounding components | Support electrical bonding and grounding requirements |
| Optional cable accessories | Organize PV cables beneath the module array |
Components may be supplied as a complete matched system or as individual solar panel mounting accessories for distributors, installers and replacement requirements.
The AL6005-T5 solar mounting system offers a practical balance between mechanical strength, corrosion resistance and low component weight. Compared with heavier structural materials, the aluminum profiles are easier to transport, lift and position on pitched roofs.
The anodized surface helps protect the aluminum PV roof mounting system against long-term outdoor exposure. SUS304 stainless steel is used for roof hooks and selected fasteners to provide reliable connections under changing temperature and weather conditions.
Custom aluminum solar rails can be supplied in different lengths and profiles according to container loading, module arrangement and installation requirements.
During installation, selected roof tiles are temporarily lifted to expose the supporting roof structure. The roof hooks are fixed to the wooden rafters or other approved structural members. The tiles are then repositioned, and the aluminum rails are connected to the hooks.
This installation method helps avoid drilling directly through exposed tile surfaces. However, waterproof flashing, sealing and tile modification requirements must be determined according to the actual tile profile, roof construction and local installation code.
Adjustable hook options help installers:
Selected aluminum solar panel roof mounting brackets and connection components can be pre-assembled before shipment. This reduces the number of loose parts handled on the roof and helps installers shorten positioning and fastening time.
For larger EPC or distribution orders, individual components can also be labeled and packed by project zone, roof section or installation sequence.
This lightweight tile roof solar racking system is suitable for:
Both portrait and landscape layouts are available, subject to module dimensions, roof geometry and structural calculations.
Huitai supports standard production and project-based customization. Available options include:
Before production, the final component configuration should be confirmed through drawings or approved samples.
| Project condition | Suitability | Selection note |
|---|---|---|
| Residential tile roof | Recommended | Lightweight and modular configuration |
| Villa rooftop PV | Recommended | Silver or black finish available |
| Commercial distributed PV | Recommended | Project-specific rail span calculation required |
| Roof with limited additional load | Recommended | Lower structural weight than stainless steel |
| Projects with high installation labor costs | Recommended | Lighter components improve rooftop handling |
| Distributor standard mounting kits | Recommended | Standard rails and clamps simplify inventory |
| High-wind area | Suitable after calculation | Reduce rail span or hook spacing where required |
| High-snow area | Requires design confirmation | Select rail section according to load |
| Severe coastal or chemical environment | Requires review | Confirm alloy, anodizing and fastener specification |
| Highly customized welded structure | Consider stainless steel | Aluminum system is based mainly on extruded profiles |
Packaging & Delivery
| Package Size | 25.00cm * 20.00cm * 27.00cm |
| Package Gross Weight | 500.000kg |
Yes. Different roof hook designs can be selected for Roman, Spanish, flat, hollow, standard and double-slot tiles. Tile drawings or photographs are recommended before final selection.
Yes. The system can include roof hooks, aluminum rails, rail connectors, mid clamps, end clamps, fasteners and optional grounding accessories.
Yes. The main aluminum mounting components use AL6005-T5 alloy, while roof hooks and selected fasteners use SUS304 stainless steel.
The system is compatible with most standard framed PV modules. Module dimensions and frame thickness should be provided before confirming the clamp and rail configuration.
Yes. Both layouts are available, subject to the roof dimensions, module size, rail arrangement and structural design.
Yes. Hook height, shape, hole position, adjustment range and other dimensions can be customized according to tile and roof conditions.
The reference maximum wind speed is up to 60 m/s, and the design snow load is up to 1.4 kN/m². Final capacity must be checked against the complete project design.
Please provide roof dimensions, tile information, module specifications, layout, project location, wind and snow requirements, order quantity and delivery destination.
Send your roof drawings, tile photographs, module specifications and required quantity to Huitai. Our team will help configure the appropriate aluminum tile roof solar mounting system, prepare the component list and provide a project-based quotation.
*Economic and energy savings: GTERGY Tile Roof Solar Mounting Bracket made of stainless steel 304&Aluminum 6005-T5 material, high strength&resistance corrosion, easy installation, no harmful waste is generated.
* Easy installation:The steel roof hook is designed for almost all the Spanish tile roof installation, it can be directly mounted on the wooden beam and rafter.
*Sustainability : We are committed to always maintaining a positive and respectful attitude both with the natural environment and with the society of which we are an active part.
* Most Compatible: Can match various solar panels.
* Pre assemble available for quick installation and save more labor cost.
* Durable and 25 years long life time, widely application for most residential, commercial and BIVP projects.
* Durable and 25 years long life time, widely application for most residential, commercial and BIVP projects.
| Product Name | Solar Tile Roof Mounting System | Material | Stainless Steel 304&Aluminum 6005-T5 | |
| Design Snow Load | Up to 30psf(1.4KN/m2) | Installation Angle | 90° or 180° | |
| Surface Treatment | Anodizing 13 um/Sand Blasting | Max Wind Speed | Up to130mph(60m/s) | |
| Design Standard | JIS C 8955:2011,GB50009-2012,1BC 2009.CBC2010 | |||
| Panel Direction | Hot-dip galvanized/zinc-aluminum-magnesium | |||
| Installation | Hollow tile/Flat roof tile/Standard tile/Double slot tile/Roman til rooftop | |||
| Application | Compatible with almost market panels | |||
| Packing | cardboard box, custom pallet or custom wooden box | |||
| Warranty | 12years | |||
| Durable | 25 years | |||
| Deliver time | Ship by FedEx/UPS/DHL takes 3-7 days; ship by sea 15-30 days |
