Anodized AL6005-T5 Aluminum Metal Roof Solar Mounting System
Share
Product Details
The AL6005-T5 Aluminum Metal Roof Solar Mounting System is designed for commercial and industrial rooftop PV projects where low structural weight, corrosion resistance and fast installation are key priorities. Its anodized aluminum rails are combined with SUS304 fasteners and roof-specific attachments to form a stable mounting structure for trapezoidal, corrugated and compatible standing seam metal roofs.
For other roof structures and material configurations, view our complete Solar Metal Roof Mounting System range.
| Model NO. | Solar Metal Roof Mounting System | Certification | ISO, CB, CE | |
| Application | Home, Industrial, Commercial | Specification | Normal, Customized | |
| Material | Anodized Al6005-T5, HDG Steel Q235B, SUS304 | Foundation | Tin Roof | |
| Snow Load | up to 1.4kN/M² | Max Wind Speed | up To130mph(60m/S) | |
| Module Orientation | Portrait or Landscape | Transport Package | Customized | |
| Origin | China | Trademark | HUITAI |
This anodized aluminum solar roof mounting system is recommended for projects that require:
It is particularly suitable for factories, warehouses, logistics centers, workshops, commercial buildings and other rooftops where minimizing structural weight is important.
For coastal, chemical-processing or other highly corrosive environments, the required anodizing thickness, stainless steel grade and material compatibility should be confirmed during project engineering.
| Parameter | Standard Configuration | Project Options |
|---|---|---|
| Main structural material | AL6005-T5 aluminum alloy | Customized profile section and rail length |
| Surface treatment | Anodized | Anodizing specification based on corrosion environment |
| Fasteners | SUS304 stainless steel | Selected according to project environment |
| Installation foundation | Tin or metal roof | Trapezoidal, corrugated or compatible standing seam roof |
| Maximum wind speed | Up to 60m/s | Final value subject to structural calculation |
| Maximum snow load | Up to 1.4kN/m² | Designed according to local snow conditions |
| Module orientation | Portrait or landscape | Customized array layout |
| Applicable modules | Framed or frameless modules | Mono, polycrystalline and compatible double-glass modules |
| Design reference | Project-specific engineering | AS/NZS 1170, JIS C 8955:2017, GB 50009, DIN 1055 or applicable local code |
| Warranty / service life | 10 years / up to 25 years | Subject to environment and maintenance conditions |
| Packaging | Export packaging | Cartons, pallets or wooden cases |
| Metal Roof Type | Typical Attachment | Important Selection Point |
|---|---|---|
| Trapezoidal metal roof | L-feet, short rail or project-specific bracket | Check rib width, sheet thickness and purlin position |
| Corrugated metal roof | Hanger bolt or adjustable roof bracket | Confirm wave dimensions and waterproof sealing method |
| Standing seam roof | Compatible non-penetrating seam clamp | Seam shape and clamp pull-out capacity must be verified |
| Metal sandwich panel | Attachment connected to the supporting structure | Do not rely only on the thin external metal sheet |
AL6005-T5 aluminum offers a favorable strength-to-weight ratio. The lighter structure is useful for warehouses and industrial roofs with limited additional load capacity.
Lightweight rails and pre-assembled brackets are easier to move across large rooftops, helping installers reduce lifting requirements and installation time.
The system can be configured with customized aluminum solar rails, solar panel clamps and roof attachments according to the roof profile and module dimensions.
Anodized aluminum and SUS304 fasteners provide reliable outdoor corrosion resistance. The exact anodizing requirement should be selected according to humidity, salt exposure and industrial pollutants.
| Selection Factor | AL6005-T5 Aluminum System | Q235B HDG Steel System |
|---|---|---|
| Structural weight | Lower; preferred for lightweight roofs | Higher; roof capacity must be checked |
| Handling | Easier rooftop transport and installation | May require more labor or lifting support |
| Corrosion protection | Anodized aluminum | Controlled by hot-dip galvanized coating |
| Structural characteristic | High strength-to-weight ratio | High rigidity and robust steel sections |
| Best suited for | Lightweight, corrosion-sensitive and installation-efficient projects | Strong industrial roofs and cost-controlled steel structures |
If structural rigidity and steel-based project economics are the main priorities, compare this product with our Q235B Hot-Dip Galvanized Steel Metal Roof Solar Mounting System.
For an accurate layout, bill of materials and quotation, please provide:
Packaging & Delivery
| Package Size | 25.00cm * 20.00cm * 27.00cm |
| Package Gross Weight | 500.000kg |
It can be configured for common trapezoidal, corrugated and standing seam roofs, but the attachment must match the exact roof profile. Roof sheet thickness, seam geometry and purlin position should be checked before quotation.
No. Up to 60m/s is the system's maximum design capability. The final allowable wind speed depends on rail span, attachment spacing, building height, roof zone and local design code.
Yes. Rail lengths, clamp positions, attachment quantities, module orientation and export packaging can be customized based on the approved project layout.
Product Description
1. Lightweight, easy transportation and installation, safe construction.
2. High corrosion resistance, salt tolerance.
3. Maximum pre-assembly, save construction time and labor cost.
4. Environmental protection, suitable for variety of geological conditions. It is durable and recyclable.
5. Many solutions to meet different customers` requirements.
6.Professional structural design to ensure the strength of the bracket system;
7.Lightweight stand, good flexibility and strength;
8.Flexible and easy component installation, saving labor cost and installation time;
9.Various installation methods, suitable for trapezoidal tin roof;
10.For commercial or residential use.
