Q235B Hot-Dip Galvanized Steel Metal Roof Solar Mounting System
10-Year Warranty Solar Panel Mounting System
25-Year Service Life PV Mounting Brackets
216km/h Wind Load Solar Panel Roof Mounting Brackets
| Brand Name: | HuiTai |
| Certificate: | CE,ISO9001,SGS |
Share
Product Description
The Q235B Hot-Dip Galvanized Steel Metal Roof Solar Mounting System is developed for industrial rooftop PV projects that prioritize structural rigidity, robust steel profiles and project-based cost control. Hot-dip galvanized Q235B components are combined with compatible roof attachments and SUS304 fasteners to support solar arrays on structurally suitable tin and metal roofs.
This system is primarily intended for factories, production facilities, warehouses and other commercial buildings with verified roof and purlin load capacity. It should not be selected solely by material price—the additional steel weight, galvanized coating requirement and roof connection design must also be evaluated.
View the complete metal roof solar mounting system range for other roof and material options.
| Model NO. | Solar Metal Roof Mounting System | Condition | New | |
| Certification | ISO, CB | Application | Home, Industrial, Commercial | |
| Specification | Normal, Customized | Material | Anodized Al6005-T5, HDG Steel Q235B, SUS304 | |
| Foundation | Tin Roof | Max Wind Load | up to 60m/S | |
| Snow Load | up to 1.4kN/M² | Module Orientation | Portrait or Landscape | |
| Transport Package | Customized | Trademark | Cardboard Box, Custom Pallet or Custom Wooden Box | |
| Transport Package | Customized | Trademark | HUITAI |
| Project Requirement | Q235B Steel System Response |
|---|---|
| Main material | Q235B carbon steel with hot-dip galvanized surface protection |
| Structural priority | Rigid steel sections for industrial roof mounting layouts |
| Roof requirement | Roof sheets, purlins and supporting structure must be verified |
| Environmental requirement | Galvanized coating specification selected according to corrosion exposure |
| Project delivery | Custom profiles, hole positions, component quantities and export packaging |
| Parameter | Available Specification | Procurement Note |
|---|---|---|
| Main structural material | Q235B carbon steel | Profile dimensions customized by structural design |
| Surface treatment | Hot-dip galvanized | Zinc coating requirement must be confirmed before production |
| Fasteners | SUS304 stainless steel | Isolation measures may be required between dissimilar metals |
| Installation location | Tin or metal roof | Roof and purlin capacity must be verified |
| Maximum wind speed | Up to 60m/s | Subject to project-specific structural calculation |
| Maximum snow load | Up to 1.4kN/m² | Rail span and attachment spacing may change |
| Module orientation | Portrait or landscape | Configured according to roof dimensions |
| Applicable modules | Framed or frameless modules | Clamp selection depends on module frame and loading |
| Design references | AS/NZS 1170, JIS C 8955:2017, GB 50009 and DIN 1055 | Local code requirements take priority |
| Warranty | 10 years | Subject to environment, coating and correct installation |
| Designed service life | Up to 25 years | Requires proper coating protection and maintenance |
| Packaging | Customized export packaging | Cartons, pallets or wooden cases |
For lightweight or corrosion-sensitive roofs, review the Anodized AL6005-T5 Aluminum Metal Roof Solar Mounting System.
The performance of a Q235B galvanized steel solar mounting system depends not only on the steel grade but also on the galvanized coating, fabrication process and installation details.
The system can be configured using project-specific steel channels, roof brackets, module clamps and solar fasteners. Component sections, wall thicknesses, hole positions, connection plates and packaging can be adjusted according to approved structural drawings.
Pre-assembly can be arranged where practical to reduce rooftop measurements and installation steps. Final component quantities should be determined from the approved array layout rather than estimated only from the total number of modules.
Our technical support team can evaluate the supplied roof information and prepare a project-based component layout and bill of of materials.
Packaging & Delivery
| Package Size | 25.00cm * 20.00cm * 27.00cm |
| Package Gross Weight | 500.000kg |
No. Steel components are heavier than equivalent aluminum components. The metal roof, purlins and main building structure must have sufficient capacity for the mounting system, solar modules and environmental loads.
The required coating should be selected according to the project location, humidity, salt exposure, industrial pollutants and expected service life. Include the required coating specification in the RFQ instead of relying only on the description “hot-dip galvanized.”
The system can be engineered for wind speeds up to 60m/s, but the final capacity depends on the profile section, connection design, attachment spacing, roof strength and local building code.
Yes. Profile dimensions, wall thicknesses, hole patterns, connection plates and packaging can be customized after the structural layout and production drawing are approved.
1. Lightweight, easy transportation and installation, safe construction.
2. High corrosion resistance, salt tolerance.
3. Maximum pre-assembly, save construction time and labor cost.
4. Environmental protection, suitable for variety of geological conditions. It is durable and recyclable.
5. Many solutions to meet different customers` requirements.
6.Professional structural design to ensure the strength of the bracket system;
7.Lightweight stand, good flexibility and strength;
8.Flexible and easy component installation, saving labor cost and installation time;
9.Various installation methods, suitable for trapezoidal tin roof;
10.For commercial or residential use.
| Material | Anodized AL6005-T5, HDG steel Q235B, SUS304 |
| Foundation | Tin roof |
| Warranty | 10 years warranty and 25 years service life |
| Standard | AS/NZS1170, JIS C8955:2017, GB50009-2012, DIN 1055, IBC 2006 |
| Max Wind Load | Up to 60m/s |
| Snow Load | Up to 1.4KN/M² |
| Applicable Module | Framed Or Frameless,Mono-crystalline, Poly-crystalline, Double |
| Module Orientation | Portrait or Landscape |
